HWRS Hydraulic Wire Rod Straightener HS-3510
Model ID：HS-3510About This Machine
The maximum cutoff diameter capability of our cold formers is Ø 44mm.
We found that it is impossible to straighten the coil of such outer diameter by people. It would be easier to do this job with a handy tool. Therefore, we developed a machine which can be easily used to straighten coil steel.
This machine has high mobility due to its light body. Besides, you can easily straighten the coil steel by pressing one button only.
We are glad to inform you that our new design of Hydraulic Wire Rod Straightener, HS-3510, has been released.
The main difference between these two is that we lighten the holder’s weight by adding some holes on the holder. In this way, the weight becomes 5.68KG, which is 12% lighter than the old design.
This change saves users’ efforts to straighten the wire rod. Please feel free to contact us if you are interested in this machine.
HOW IT WORKS
When we want to feed the coil into machine, we will use Hydraulic Wire Straightener, also called Coil bender, to make wire rod straight. The material demonstrated in the video is 6140, 0.4% carbon, middle carbon alloy steel. And the outer diameter is Ø31.5 mm.
OPERATION STEPS
Set the wire rod on the machine.
Cylinder head starts to push the bending part when pressing down the button.
Wire rod becomes straight.
